Cadjebut, Goongewa (12 Mile Bore)
Western Australia, WA, Australia
Main commodities: Zn Pb


Our Global Perspective
Series books include:
Click Here
Super Porphyry Cu and Au

Click Here
IOCG Deposits - 70 papers
All available as eBOOKS
Remaining HARD COPIES on
sale. No hard copy book more than  AUD $44.00 (incl. GST)
The Cadjebut deposit is located ~70 km SW of Fitzroy Crossing in Western Australia.
(#Location: 18° 42' 43"S, 125° 57' 42"E).

The Cadjebut orebody occurs within the middle to upper Devonian Pillara Limestone on the Lennard Shelf in north-western WA. The exposed sections on the Lennard Shelf comprise mainly shallow marine carbonate and associated basinal siltstone and shale, and extend over 350 km interval in a WNW-ESE direction along the southern margin of the Kimberley block. Locally these unconformably overlie Ordovician carbonates. Cadjebut, like the other Zn-Pb mineralisation of the shelf, is hosted by platform, reef, fore-reef and shelf facies carbonates, ranging in composition from calcareous siltstone and shale, through silty dolomite to clean fossiliferous reef and platform limestone. The host unit is locally 450 m thick and has a basal arkosic siltstone, a lower dolomite, vuggy dolomite, and an upper dolomite.

The Cadjebut orebody comprises two strongly elongate and weakly sinuous stratabound 'ribbon-like' lenses, stacked one immediately above the other. These lenses plunge to the ESE at around 6° to 8°, generally parallel to the dip of bedding, and dip shallowly to flat to the NNE. They are each 80 to 100 m wide on average, but locally up to 150 m, are 3000 m long and from 4.2 to 4.6 m thick using a 7% Zn+Pb cut-off. The two lenses are separated by 6 m of interburden.

The high grade mineralisation is predominantly situated within carbonate-siltstone units, with the sulphides replacing the host rock, either through open space filling of pre-existing cavities or more direct replacement along more permeable lithological units. There are four types of ore, namely:
i). open space filling sphalerite and galena within solution collapse breccia above the type 2 ore;
ii). banded replacement ore composed of thin bands of multi-coloured ribbon sphalerite ore, with banding not parallel to bedding. These are found near the base of each of the two ore lenses, being around 30 cm thick, but of very high grade;
iii). late stage galena veins and veinlets; and
iv). massive marcasite found on the lateral margins of the ore.

The general paragenesis appears to proceed from country rock (with corroded margins) to several pulses of fine grained cream to brown coloured sphalerite with coarse galena to purple-brown coarse grained colloform sphalerite to coarse grained marcasite to coarse grained galena and lastly calcite.

The initial pre-mining reserve of 4.4 Mt @ 11.3% Zn, 3.3% Pb (Tompkins et al., 1997).

The Cadjebut deposit was discovered in 1984 by BHP. BHP commenced development in 1987, and the mine was opened in 1988, but sold in 1994, with its other Lennard Shelf interests, to Western Metals (Wilkinson, 1994). Mining continued until 1998 (Western Metals Limited, 1999).

The Goongewa deposit, initially known as 12 Mile Bore, is located ~15 km NW of the Cadjebut Mine. It was discovered by BHP in 1985, and occurs in the hanging wall of the Cadjebut Fault, at the contact between the dolomitised and un-dolomitised carbonates. Sulphides occur as cavity filling cements, and include sphalerite stalactites, indicating an open or gas filled space during near surface mineralisation. The orebody also contains calcite, sphalerite, galena, pyrite, marcasite and significant silver values. The Goongewa orebody forms a series of irregular shaped pods, located 100 to 250 metres below the surface.

The Goongewa mine produced 2.51 Mt @ 7.54% Zn, 2.36% Pb from underground between 1995 and its closure in March 2001 (Western Metals Limited, 2002).

The most recent source geological information used to prepare this decription was dated: 2004.
This description is a summary from published sources, the chief of which are listed below.
© Copyright Porter GeoConsultancy Pty Ltd.   Unauthorised copying, reproduction, storage or dissemination prohibited.


Cadjebut

  References & Additional Information
   Selected References:
Christensen J N, Halliday A N, Vearncombe J R, Kesler S E  1995 - Testing models of large-scale crustal fluid flow using direct dating of Sulfides: Rb-Sr evidence for early dewatering and formation of Mississippi Valley-type deposits, Canning Basin, Australia: in    Econ. Geol.   v90 pp 877-884
Murphy G C  1990 - Lennard Shelf Lead-Zinc deposits: in Hughes F E (Ed.), 1990 Geology of the Mineral Deposits of Australia & Papua New Guinea The AusIMM, Melbourne   Mono 14, v2 pp 1103-1109
Tompkins L A, Eisenlohr B, Groves D I, Raetz M  1997 - Temporal changes in mineralization style at the Cadjebut Mississippi Valley-type deposit, Lennard Shelf, W.A.: in    Econ. Geol.   v92 pp 843-862
Tompkins L A, Pedone V A, Roche M T, Groves D I  1994 - The Cadjebut deposit as an example of Mississippi Valley-type mineralization on the Lennard Shelf, Western Australia - single episode or multiple events?: in    Econ. Geol.   v 89 pp 450-466
Tompkins L A, Rayner M J, Groves D I  1994 - Evaporites: in situ Sulfur source for rhythmically banded ore in the Cadjebut Mississippi Valley-type Zn-Pb deposit, Western Australia: in    Econ. Geol.   v 89 pp 467-492
